In ferroalloy production, the efficiency and stability of submerged arc furnaces are directly influenced by the system power factor. Traditionally, after a furnace is built and put into operation, the natural power factor is usually only 0.60–0.65. Such a low power factor not only leads to inefficient energy utilization but also restricts the effective output capacity of the furnace.
CHNZBTECH provides an advanced Low Voltage Compensation (L.V. Compensation) System, specially designed to improve the operating power factor of submerged arc furnaces to 0.90–0.95. By raising the power factor, more active power is delivered to the furnace, resulting in significant increases in production output and improved energy efficiency.
Power Factor Improvement: Increases furnace power factor from 0.60–0.65 to 0.90–0.95.
Higher Production Capacity: Ensures more effective active power, enabling substantial output growth.
Energy Efficiency: Reduces reactive power losses and lowers electricity consumption per ton of ferroalloy.
Stable Operation: Improves voltage stability, reduces fluctuations, and extends equipment service life.
Customized Design: Tailored solutions to match different furnace sizes and transformer capacities.
Item | Parameter | Notes |
Applicable furnace type | Submerged arc furnace (ferroalloy, SiC, FeSi, Mn, etc.) | Customized design available |
Rated voltage | 0.4 kV – 1 kV | Match with L.V. distribution |
Compensation capacity | 5 – 50 Mvar | Configured according to furnace transformer rating |
Power factor before compensation | 0.60 – 0.65 | Natural status of newly built furnace |
Power factor after compensation | 0.90 – 0.95 | Adjustable according to operation |
Response time | ≤ 40 ms | Rapid dynamic compensation |
Control method | Automatic switching / Thyristor-controlled | Optional |
Cooling method | Natural air cooling / Forced air cooling | According to system size |
Installation mode | Indoor panel type / Outdoor container type | Flexible arrangement |
Service life | ≥ 15 years | Under normal operating conditions |
Standards | IEC, IEEE, GB | Compliance with international standards |
